LSTM简易通用版本

下载链接

因为在数学建模中用的很麻烦，写了个简易易使用版本。

以下代码为最终成品代码 demo 版本，不推荐使用，最新版本可点下载链接或可见 csdn。

import torch
import torch.nn as nn
import numpy as np
import matplotlib.pyplot as plt
import torch.nn.functional as F
import warnings
import pandas as pd
import scipy.stats as st

# 设定随机种子，以确保实验的可重复性
torch.manual_seed(1)
np.random.seed(1)


# 定义LSTM模型
class LSTM(nn.Module):
    hidden = None

    def __init__(self, input_size, hidden_size, output_size, num_layers):
        super().__init__()
        self.hidden_size = hidden_size
        self.num_layers = num_layers
        self.train_on_gpu = torch.cuda.is_available()
        # As batch_first=True, input: (batch_size, sequence_length, input_size)
        self.lstm = nn.LSTM(input_size, hidden_size, num_layers, batch_first=True)
        self.lstm2 = nn.LSTM(hidden_size, hidden_size, num_layers, batch_first=True)
        self.fc = nn.Linear(hidden_size, hidden_size)
        self.fcOut = nn.Linear(hidden_size, output_size)
        self.drop = nn.Dropout(0.5)
        # 可选操作，可以把下一行注释
        self.apply(LSTM.init_weights)

    def forward(self, x):
        # 防止 loss.backward 报错
        hidden = [each.data for each in self.hidden]
        x, hidden = self.lstm(x, hidden)
        x, self.hidden = self.lstm2(x, hidden)
        x = x[:, -1, :]
        x = F.relu(self.fc(x))
        x = self.drop(x)
        x = self.fcOut(x)
        return x

    def init_hidden(self, batch_size):
        weight = next(self.parameters()).data

        if self.train_on_gpu:
            self.hidden = (weight.new(self.num_layers, batch_size, self.hidden_size).zero_().cuda(),
                           weight.new(self.num_layers, batch_size, self.hidden_size).zero_().cuda())
        else:
            self.hidden = (weight.new(self.num_layers, batch_size, self.hidden_size).zero_(),
                           weight.new(self.num_layers, batch_size, self.hidden_size).zero_())

    @staticmethod
    def init_weights(m):
        if type(m) == nn.LSTM:
            for name, param in m.named_parameters():
                if 'weight_ih' in name:
                    torch.nn.init.orthogonal_(param.data)
                elif 'weight_hh' in name:
                    torch.nn.init.orthogonal_(param.data)
                elif 'bias' in name:
                    param.data.fill_(0)
        elif type(m) == nn.Conv1d or type(m) == nn.Linear:
            torch.nn.init.orthogonal_(m.weight)
            m.bias.data.fill_(0)


class CustomLSTM:
    X, Y, data, model, optimizer, criterion, result, result_, window, losses = [None] * 10

    def __init__(self, data: np.array, window):
        self.data = data
        self.input_dim = self.init_data()
        self.output_dim = self.input_dim
        self.slice(window)

    # data 可为一维数组或二维数组，强制把一维数组转化为二维数组
    def init_data(self):
        assert (length := len(self.data.shape)) in [1, 2]
        if length == 1:
            self.data = self.data[:, np.newaxis]
        return len(self.data[0])

    # 检查总数据大小是否能整除 batch
    def check_batch(self, batch_size):
        length = self.X.shape[0]
        # 保证 batch_size 比总长度小
        assert length >= batch_size
        if batch_size * (length // batch_size) != length:
            warnings.warn(f'数据大小为{length}, batch大小为{batch_size},无法整除,会损失{(length % batch_size) / length * 100}%数据', DeprecationWarning)

    # 以 window 为窗口大小切片形成整个batch
    def slice(self, window):
        self.window = window
        X, Y = [], []
        for i in range(len(self.data) - window):
            X.append(self.data[i:i + window])
            Y.append(self.data[i + window])
        X = np.array(X)
        Y = np.array(Y)
        X = torch.from_numpy(X).float()  # (batch_size, sequence_length, input_size)
        Y = torch.from_numpy(Y).float()
        print(f"数据格式:X = {X.shape}, Y = {Y.shape}")
        self.X = X
        self.Y = Y

    def re_slice(self, window):
        self.X, self.Y, self.model, self.optimizer, self.criterion, self.result, self.result_, self.losses = [None] * 9
        self.slice(window)

    # 初始化 LSTM model
    def init_lstm(self, hidden=64, lr=0.001, num_layers=1):
        self.model = LSTM(self.input_dim, hidden, self.output_dim, num_layers)
        self.optimizer = torch.optim.Adam(self.model.parameters(), lr=lr)
        self.criterion = nn.MSELoss()
        if torch.cuda.is_available():
            self.model.cuda()
            self.X.cuda()
            self.Y.cuda()

    # 总数据产生 batch 并可以进行 shuffle
    @staticmethod
    def iterate_batches(inputs, targets, batchsize, shuffle=True):
        assert len(inputs) == len(targets)
        if shuffle:
            indices = np.arange(len(inputs))
            np.random.shuffle(indices)
        for start_idx in range(0, len(inputs) - batchsize + 1, batchsize):
            if shuffle:
                excerpt = indices[start_idx:start_idx + batchsize]
            else:
                excerpt = slice(start_idx, start_idx + batchsize)
            yield inputs[excerpt], targets[excerpt]

    # 开始训练
    def train(self, num_epochs=100, batch_size=128, max_batch=False):
        losses = []
        if self.model is None:
            raise ValueError("请先使用CustomLSTM.init_lstm初始化网络")
        if max_batch:
            batch_size = self.X.shape[0]
        else:
            self.check_batch(batch_size)
        for epoch in range(num_epochs):
            loss_all = 0
            self.model.init_hidden(batch_size)
            for index, (batch_x, batch_y) in enumerate(CustomLSTM.iterate_batches(self.X, self.Y, batch_size, shuffle=True)):
                self.optimizer.zero_grad()
                outputs = self.model(batch_x)
                loss = self.criterion(outputs, batch_y)
                loss.backward()
                self.optimizer.step()
                loss_all += loss.detach().cpu()
            losses.append(loss_all / (index + 1))
            if epoch % 20 == 0:
                print('Epoch [{}/{}], Loss: {:.4f}'.format(epoch + 1, num_epochs, loss_all / (index + 1)))
        self.losses = losses
        self.predicted()

    def plot_loss(self):
        if self.losses is None:
            raise ValueError("loss 不存在，请先进行训练")
        plt.figure(figsize=(12, 6))
        plt.plot(self.losses)
        plt.xlabel("Epoch")
        plt.ylabel("Loss")
        plt.show()

    # 预测之后 n 天的值
    def predict(self, n):
        # self.predicted()
        self.model.init_hidden(1)
        data = self.data[-self.window:, :].tolist()
        y = []
        for i in range(n):
            x = torch.tensor(data).float().unsqueeze(0)
            result = self.model.cpu()(x).tolist()
            y.append(result[0])
            data.append(result[0])
            data.pop(0)
        self.result = np.array(y)
        return self.result

    # 预测从 window_size 到结束数据的预测值，以便与真实值做比较
    def predicted(self):
        self.model.eval()
        self.model.init_hidden(len(self.X))
        with torch.no_grad():
            predicted = self.model(self.X)
            predicted = predicted.detach().cpu().numpy()
        self.result_ = predicted
        return self.result_

    # 因为可以为二维数组即对多个变量进行预测，names即为每个变量的名字
    def plot(self, names=None):
        if self.result is None:
            raise ValueError("请先使用CustomLSTM.predict")
        if names is None:
            names = [None] * len(self.data[0])
        # further = self.predict(n)
        x = np.arange(len(self.data))
        x_further = np.arange(len(self.data), len(self.data) + len(self.result))
        plt.figure(figsize=(12, 6))
        for i in range(len(self.data[0])):
            plt.plot(x, self.data, label=f'{names[0]} True Values')
            plt.plot(x[self.window:], self.result_[:, i], label=f'{names[0]} Predictions')
            plt.plot(x_further, self.result[:, i], label=f"{names[0]} Further Predictions")
        plt.show()

    # 画置信区间，demo 版本
    # ToDo
    def plot_confidence(self, index=0, alpha=0.05):
        if self.result is None:
            raise ValueError("请先使用CustomLSTM.predict")
        plt.figure(figsize=(12, 6))
        x = np.arange(len(self.data))
        x_further = np.arange(len(self.data), len(self.data) + len(self.result))
        y_true = self.data[self.window:, index].tolist()
        plt.plot(y_true, label='True Values')
        plt.plot(x_further, self.result[:, index], label="Further Predictions")
        plt.plot(x[self.window:], self.result_[:, index], label='Predictions')

        y_pred = self.result[:, index]
        lower, upper = Utils.ci(y_true, y_pred, alpha=alpha)
        plt.plot(y_pred, label='Predictions')
        plt.fill_between(np.arange(), lower, upper, alpha=0.2, label='Confidence interval')
        plt.legend()
        plt.show()

    # 打印 summary， 即 r^2 评价函数等
    def summary(self):
        if self.model is None:
            raise ValueError("请先进行训练")
        print("==========Summary Begin===========")
        print("R2   =", score_r2 := Utils.r2(self.result_, self.data[self.window:, :]))
        print("MSE  =", score_mse := Utils.mse(self.result_, self.data[self.window:, :]))
        print("RMSE =", score_rmse := np.sqrt(score_mse))
        print("MAE  =", score_mae := Utils.mae(self.result_, self.data[self.window:, :]))
        print("===========Summary end============")
        return score_r2, score_mse, score_rmse, score_mae


# 工具
class Utils:
    # 置信区间，demo
    # ToDo
    @staticmethod
    def ci(y_true, y_pred, alpha=0.05):
        residuals = y_true - y_pred
        n = len(residuals)
        df = n - 1
        t_value = st.norm.ppf(1 - alpha / 2, df)
        std_err = np.std(residuals, ddof=1) / np.sqrt(n)
        upper = residuals + t_value * std_err
        lower = residuals - t_value * std_err
        return lower, upper

    # r2 评价函数
    @staticmethod
    def r2(y_pred, y_true):
        return 1 - ((y_pred - y_true) ** 2).sum(axis=0) / ((y_true.mean(axis=0) - y_true) ** 2).sum(axis=0)

    @staticmethod
    def mse(y_pred, y_true):
        return ((y_true - y_pred) ** 2).sum(axis=0) / len(y_pred)

    @staticmethod
    def rmse(y_pred, y_true):
        return np.sqrt(((y_true - y_pred) ** 2).sum(axis=0) / len(y_pred))

    @staticmethod
    def mae(y_pred, y_true):
        return (np.absolute(y_true - y_pred)).sum(axis=0) / len(y_true)

    # 添加快捷打开文件操作
    @staticmethod
    def openfile(name):
        file_type = name.split(".")[-1]
        if file_type == "csv":
            df = pd.read_csv(name, encoding='GBK')
        elif file_type == "xlsx" or file_type == "xls":
            df = pd.read_excel(name)
        else:
            raise TypeError(f"{name} 类型不是 csv, xls, xlsx")
        # df = df[["列名字1", "列名字2"]]
        print(df)
        return np.array(df)


def load_data():
    # 以下注释代码为快捷打开操作
    # return Utils.openfile(file_location)
    data = np.sin(np.arange(100) * np.pi / 50) + np.random.randn(100) * 0.1
    return data


if __name__ == "__main__":
    # 加载数据
    data = load_data()

    # 初始化网络
    window_size = 10
    batch = 100
    lstm = CustomLSTM(data, window_size)
    lstm.init_lstm(hidden=64, lr=0.001, num_layers=1)

    # 训练网络
    # max_batch 表示是否以整一个数据作为 batch 不做分割
    lstm.train(num_epochs=1000, max_batch=True)
    # lstm.train(num_epochs=50, batch_size=30, max_batch=False)

    # 调整窗口大小重新训练
    # lstm.re_slice(20)
    # lstm.init_lstm(hidden=64, lr=0.001, num_layers=1)
    # lstm.train(num_epochs=50, batch_size=40, max_batch=False)

    # 打印 summary
    r2, mse, rmse, mae = lstm.summary()

    # 预测之后 100 步数据
    lstm.predict(100)

    # 画图
    lstm.plot_loss()
    lstm.plot(['data'])
    # lstm.plot_confidence(index=0)
